77
Sending Documents via LAN
Transmission Reservation
You can reserve the next transmission into memory for up to 30 different documents while sending a
document from memory or receiving a document via LAN.
Memory Transmission Reservation (Dual Access)
If your machine is on-line and busy transmitting from memory, receiving, or printing received documents, you
can reserve transmission by using the following procedure.
Your machine is on-line, the ON LINE lamp is blinking or
printing received documents.
Set document(s) face down.
MEMORY
Make sure that the MEMORY lamp is on.
If not, press MEMORY to set ”On”.
Enter email addresses
(a) Enter by any combination of the following methods:
(Up to 200 stations)
• One-Touch Dialling
• Abbreviated Dialling
• Directory Search Dialling, press SET after each
email address is entered.
(b) Enter the full email address (up to 50 addresses).
• Manual Number Dialling, press SET after each
station is entered.
• Manual Number Dialling can not be used in
combination with One-Touch and Abbreviated Dialling.
START
Your machine will store the document into memory.
To cancel the memory transmission reservation, see page 127.
04007000001
04007010002
04007040001
04003020010
#@multitude
04003050005
#@multitude
04003060032
#@multitude
04003060067
#@multitude
04003060002
#@multitude
04007060013
#@multitude2
04003060035
#@multitude
Note:
04003070019
#@multitude
ON LINE * MEM.XMT *
ID:(Identification)
ON LINE * RCV *
ID:(Identification)
* PRINTING *
MEMORY RCV’D DOC
ENTER STATION(S)
THEN PRESS START 00%
* STORE * NO.005
PAGES=01 01%
* STORE * COMPLETED
TOTAL PAGES=05 25%
4
1
2
3
4
5
